Advanced Operation
RS-232 and IP Configuration
IP Configuration
The 16x16 3G-SDI Matrix w/ Push Button Controls supports IP-based control using RS-232
or the built-in Web-based GUI. To set up IP control, the network settings for the 16x16
3G-SDI Matrix w/ Push Button Controls must be configured via RS-232. The default
network settings for the matrix are as follows:
Description IP Address / Port Description IP Address / Port
IP Address 192.168.0.72 Gateway 192.168.1.1
Subnet 255.255.255.0 HTTP port 80
1. Connect an RS-232 cable from the PC to the 16x16 3G-SDI Matrix w/ Push Button
Controls. Also make sure that an Ethernet cable is connected between the matrix and
the network.
2. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232
settings listed on the previous page.
3. Set the IP address for the matrix using the #sipadd command.
4. Set the subnet mask using the #snetmask command.
5. Set the gateway (router) IP address using the #sgateway command.
6. Set the HTTP listening port using the #sport command.
7. Reboot the matrix to apply all changes, then type the IP address that was specified in
step 3, in a Web browser to access the Web GUI.
NOTE: Depending upon the network, all related IP, Telnet, and
UDP settings will need to be assigned. Consult your network
administrator to obtain the proper settings.
