System board, Connectors – Gateway E-9525R User Manual
Page 12
CHAPTER 1: Checking Out Your Gateway Server
www.gateway.com
6
System board
Connectors
28
29
30
31
32
33
34
35
37
36
#
Feature
#
Feature
1
Rear dual USB Port (J35)
20
DIMM7 socket (J24)
2
Serial port (J31)
21
DIMM8 socket (J25)
3
ID LED (CR16)
22
Fan power/fan tach connector (J99)
