APPENDIX A: Server Specifications www.gateway.com
94
System specifications
System board specifications
Case size
(H×W×L)
3.44 Ч 16.93 Ч 27.38 inches (8.75 Ч 43.0 Ч 69.55 cm)
Weight Minimum - 40 lbs (18.14 Kg) (no bezel, power supplies, hard drives,
optical drive, diskette drive, fans, cables, and so on)
Maximum - 60 lbs (27.22 Kg) (±0.5 Kg)
Fans ■ Three dual-rotor, multi-speed system fans
■ Two single-rotor, multi-speed system fans
Ports ■ PS/2 keyboard or mouse (2)
■ USB (4 standard, 2 front and 2 back)
■ Serial
■ VGA (2 standard, 1 front and 1 back)
■ LAN (2) (RJ-45)
■ IPMI (RJ-45) for BMC
Drives
(standard)
■ One slimline drive bay for an optical drive
■ USB Floppy diskette drive (optional)
■ Tape drive (optional)
Hard drive bays Six SATA or SAS hot-swap hard drive bays
Card sizes Supports three full-length, full-height and two low-profile PCI
expansion cards
Power supply One 700 W hot-swap, power supply module (standard)
Additional 700 W hot-swap redundant power supply module
(optional)
Operating
systems
Supports Windows Server 2003 and Windows Small Business Server
2003
Certifications ■ FCC Class A
■ UL
■ cUL
Processor Supports as many as two Intel® Xeon™ 5100 series processors
Chipset ■ Intel Blackford MCH (Northbridge)
■ Intel ESB2E (Southbridge)
Memory Eight 240-pin vertical DIMM slots support from 512 MB to 32 GB of
fully-buffered (FB-DIMM) DDR2-667 compliant, 72-bit, single rank or
dual rank, SDRAM modules.
