Gateway 7450R - Manual (Page 83)

Managing the Server 75
9 Select Other devices , then click Have Disk .
10 Browse the SCCD to find 7450R.inf.
11 Select the 7450R Driver.
12 If the server does not reboot automatically, reboot the server.
13 Setup ManageX (see “Setting up ManageX” on page 75).
Setting up ManageX
To setup ManageX:
1 Run ManageX.
2 Select WBEM Browser, Systems Management Server , then 7450R Components
to see the server information.
This step displays the WBEM Object detail window. The data displayed
in this window is not updated dynamically. To view the latest data, click
the refresh button before you open the WBEM Object detail window.
3 Select the Device Selector window.
4 Click Devices to choose the server which will run ManageX.
5 Click Apply .
6 In the list of options on the left side of the screen, right-click Policies .
7 Select All Tasks , then Set Directory .
8 Accept the default installation directory \Program Files\7450R Agent.
9 Click Policies , then Available .
10 Right-click 7450RSnmpTrap.mxw .
11 Select All Tasks , then Install .
You can open the Message Reader to view the events. The Message Reader is
dynamically updated every few seconds.
You can also modify the error limit values in \winnt\7450R.ini. However,
you must stop the SNMP service and restart it when you are finished.
8507328.book Page 75 Thursday, February 15, 2001 11:28 AM
