System Features 7
G Blower 2 connector
H Jumper J1
I Blower 1 connector
J Front panel USB connector
K Power connector
L Fan 2 connector
M Front panel connector
N Fan 1 connector
O Secondary IDE connector
P Primary IDE connector
Q Diskette drive connector
R Ultra160 SCSI connector
S DIMM slots (4)
T Riser card edge connector
U RJ-45 Ethernet LAN1 connector and LEDs
V RJ-45 Ethernet LAN2 connector and LEDs
W Video connector
X Serial port
Y Stacked keyboard and mouse ports
