System Specifications 109
Electrical specifications
The computer power supply and the typical configuration conform to the
following values:
Vibration
Operating
Nonoperating
0.0032 g2/Hz 5–200 Hz, -6dB/octave 200–500 Hz
0.015 g2/Hz 5–200 Hz, -6dB/octave 200–500 Hz
Altitude
Operating
Nonoperating
10,000 ft. max
50,000 ft. max
Heat dissipation 422 BTU (loaded)
988 BTU (maximum)
Acoustic noise <55dB
AC Input Power
115 V
∼
230 V
∼
90-135 V~, 3.2 A
180-265 V~, 1.6 A
AC Input Frequency
115 V
∼
230 V
∼
47-63 Hz
47-63 Hz
Total Power 86.562 W (loaded)
* Maximum temperature refers to the inlet air temperature, which is the ambient air
temperature within the rack cabinet, not the air temperature within the room.
