Gateway 7450R - Manual (Page 50)

42 Gateway 7450R Server System Manual
6 Remove the cable over the air baffle and pull the air baffle out of the
server.
7 Using your finger or a small, flat-bladed screwdriver, carefully press the
small spring clip to remove the battery from its socket on the system
board.
8 Press the new battery in the socket with the positive pole up. Be sure you
have pressed the battery down far enough for it to contact the base of
the socket (it should snap into place).
9 Close the case. See “Closing the case” on page 20.
10 Reconnect the peripherals and the power cord, then turn on the system.
11 If the CMOS data is not correct, change the information in the BIOS Setup
utility using the data you recorded in Step 2.
Air baffle
Spring clip
