Replacing and Adding Internal Devices 37
To replace the secondary processor:
1 Turn off the system and disconnect the power cord and all external
peripheral devices.
2 Open the case. See “Opening the case” on page 18 and “Preventing static
electricity discharge” on page 17.
3 Unclip the heatsink by pressing down on the top of the clip, then pushing
the top of the clip toward the heatsink.
4 Remove the processor by pulling the lever arm slightly away from the
processor socket, then lifting it to a ninety-degree angle.
5 Lift the old processor out of the socket.
Clip
Hook
1
2
