32

s Y M P t o M

D i a g N o s i s

c H e c k

Close Edge LED ON

brightly Status Light

flashes

Close Edge terminal shorted to

Com

• Edge sensor is sensing an

obstruction.

• Relay from edge sensor is

shorted or latched.

• Wire between edge sensor and

open edge terminal is shorted.

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Open LED ON brightly

Status Light flashes

Open terminal shorted to Com

• Push button is stuck.

• Exit wand, Loop detector,

Photo beam, etc., is sensing a

presence.

• Relay from Exit wand, Loop

detector, Photo beam, etc. is

shorted or latched.

• Wire from Exit wand, Loop

detector, Photo beam, etc. is

shorted.

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Close LED ON brightly

Status Light flashes

Close terminal shorted to Com

• Push button is stuck

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Stop LED ON brightly

Status Light flashes

Stop and Com terminals open.

• W1 is cut and normally open

button is wired to Stop and Com.

• W1 is cut and no normally

closed push button is wired to

Stop and Com.

• Wire between normally closed

push button and Stop terminal is

cut or disconnected.

• Check terminal voltage with

respect to Com to ensure you

read 0 vdc.
