Owner’s Manual
Owner’s Manual
GTO/PRO GP-SW050
AC Powered Swing Gate Operators
WARNING
Reducer /Operator Arm
Gate Bracket
1/2" Washer (2)
Plastic Spacer (1)
1/2" Nut (2)
½" – 2¾" Bolt (2)
Clevis Pin (1)
Hairpin Clip (1)
Gate Warning Signs
(one for each side)
Fully Assembled Operator
33 in
(84 cm)
TO
BASE
27 in
(69 cm)
17 in
(42 cm)
24 in
(61 cm)
13 in
(33 cm)
18 in
(46 cm)
15 in
(38 cm)
NOTE: GTO receiver (RB709U),
batteries (12vdc, U1, 230A minimum)
not included. Must order separately.
23¾ in
(60.3 cm)
19¾ in
(50.2 cm)
12½ in
(31.8 cm)
14½ in
(36.8 cm)
12½ in
(31.8 cm)
3 in
(7.6 cm)
6 in
(15.2 cm)
Operator Chassis
Parts identification
HARDWARE BAG - R4027
