30

troubleshooting guide

WarNiNg: alWaYs tUrN oPerator oFF aND DiscoNNect

Batteries BeFore aDJUstiNg or serViciNg it.

s Y M P t o M

D i a g N o s i s

c H e c k

One beep every 5 seconds

when the gate is in motion.

There is no AC power present.

The battery voltage is low.

• GFI

• Circuit Breaker

• Connections in the Field Wiring

Connection Compartment

• Battery Connections

• Battery Voltage

• Load Test Battery

One beep every 10 seconds

when the gate is idle.

The battery is critically low.

If #4 dip switch is in the FAIL SAFE

position and the gate is at the OPEN

Limit, the operator will be disabled until

AC power is restored and the battery

voltage has reached 26 vdc.

If #4 dip switch is in the FAIL SECURE

position and the gate at the CLOSED

Limit, the operator will be disabled until

AC power is restored and the battery

voltage has reached 26 vdc.

• GFI

• Circuit Breaker

• Connections in the Field Wiring

Connection Compartment

• Battery Connections

• Battery Voltage

• Load Test Battery

1 beep with 2 seconds

pause

The revolution counter circuit board is

not being detected.

• Check Connections for Limit

Sensors on Logic Board

2 beeps with 2 seconds

pause

The logic board does not detect the

motor drive board connections.

• Check BLDC Speed Control

connections on Logic Board and

Motor Drive Board

3 beeps with 2 seconds

pause

The gate has traveled outside the

maximum allowable limit of the

operator.

• Check Limit Sensor Connections

on Logic Board

4 beeps with 2 seconds

pause

The motor has moved in the wrong

direction.

• Check BLDC Speed Control

connections on Logic Board and

Motor Drive Board

5 beeps with 2 seconds

pause

No movement was detected from the

motor twice.

• Check path of Gate for

obstructions.

• Check to ensure motor is not

jammed.

gP-sW050 audible Feedback
