18

stall Force and auto-close adjustments

Stall Force Adjustment:

IMPORTANT: For safety reasons, the

STALL FORCE

potentiometers are set at the “10 o’clock” position

at the factory.

The obstruction sensitivity is independently adjustable for each direction of travel. Upon sensing an

obstruction, the gate will stop and reverse direction for approximately 2 seconds.

1. Turning the potentiometer clockwise (toward the MAX position) increases the amount of force

the operator applies to an obstruction. Turning the potentiometer counter-clockwise (toward the

MIN position) decreases the amount of force the operator applies to an obstruction.

2. Use a small screwdriver to adjust the appropriate potentiometer and operate the gate until it can

run without obstructing and reversing direction.

1

2

3

4

O

N

CYCLE

SAFETY

SHADOW

OPEN

CLOSE

STOP

OPEN

EDGE
CLOSE

EDGE

STALL FORCE ADJUST

LIMIT ADJUSTMENTS

DIAG.
PORT

RUNNING

OPTIONS

MIN

MAX

MIN

MAX

OFF

120

<<< JOG >>>

<<< >>>

SET

LIMIT

CLOSED

LED10

LED09

AUTO CLOSE

TIMER

MODE 1

MODE 2

OPEN DIR.

SLV OPN

DUAL MODE

LOW BATT

ON

ON

>>>

SIMUL

SLAVE

SECURE

OFF

OFF

<<<

DELAY

MASTER

SAFE

CYCLE

SAFETY

OPEN EDGE

RUN 2

OPEN

CLOSE

STOP

COM

COM

COM

SHADOW

LOOP

REL
AY OUTPUT

S

LOCK N.C.

LOCK COM

LOCK N.O.

RUN 1

RUN 2

CLOSED 1

CLOSED 2

1

2

3

4

O

N

CYCLE

SAFETY

SHADOW

OPEN

CLOSE

STOP

OPEN

EDGE
CLOSE

EDGE

STALL FORCE ADJUST

LIMIT ADJUSTMENTS

DIAG.
PORT

RUNNING

MIN

MAX

MIN

MAX

OFF

120

<<< JOG >>>

<<< >>>

SET

LIMIT

CLOSED

LED10

LED09

SAFETY

SHADOW

OPEN

EDGE

CLOSE

EDGE

OPEN

CLOSE

STOP

C

O

M

AUTO CLOSE

TIMER

Auto-Close Adjustment:

The Auto-Close potentiometer allows the user to set the time that the gate will stay at the open

position/limit before it automatically starts to close the gate.

This feature can be turned off by turning the

AUTO CLOSE TIMER

potentiometer all the way

counter- clockwise. It is shipped from the factory in the OFF position (auto close feature is disabled).

• The auto close time is adjustable from 3-120 seconds.

• This feature is only enabled when the gate is at the open limit.

• This feature is disabled if the following inputs are activated.

• OPEN, SAFETY, SHADOW, CLS-EDGE or STOP.
