The GP-SW050 automatic gate operators are intended for use with vehicular swing gates. The operators
can be used in Class I, II, III, and IV applications.
Converting Metric Units to English Equivalents
When You Know Multiply By To Find Symbol
centimeters 0.3937 inches in. (or “)
meters 3.2808 feet ft. (or ‘)
kilograms 2.2046 pounds lb. (or #)
Converting English Units to Metric Equivalents
When You Know Multiply By To Find Symbol
inches 2.5400 centimeters cm
feet 0.3048 meters m
pounds 0.4535 kilograms kg
Temperature
deg. Celsius (ºC x 1.8) + 32 deg. Fahrenheit ºF
deg. Fahrenheit (ºF-32) / 1.8 deg. Celsius ºC
Conversion Chart
WARNING!
• READ ALL INSTRUCTIONS COMPLETELY before attempting installation and use; failure
to do so may result in serious injury or death!
• This unit must only be installed by an experienced technician!
• DANGER: HIGH VOLTAGE! Contact with gate operator circuitry can cause serious
injury or death! Operator power must be disconnected before servicing!
• This gate operator may produce a high level of force. Stay clear of the unit while it is
operating and exercise caution at all times.
VEHICULAR GATE OPERATOR class categories
class i: Residential Vehicular Gate Operator – A vehicular gate operator (or system)
intended for use in a home of one-to-four single family dwelling, or a garage or parking
area associated therewith.
class ii: Commercial/General Access Vehicular Gate Operator – A vehicular gate operator
(or system) intended for use in a commercial location or building such as a multifamily
housing unit (five or more single family units), hotel, garages, retail store, or other building
servicing the general public.
class iii: Industrial/Limited Access Vehicular Gate Operator – A vehicular gate operator
(or system) intended for use in an industrial location or building such as a factory or loading
dock area or other locations not intended to service the general public.
class iV: Restricted Access Vehicular Gate Operator – A vehicular gate operator (or
system) intended for use in a guarded industrial location or building such as an airport
security area or other restricted access locations not servicing the general public, in which
unauthorized access is prevented via supervision by security personnel.
