accessory Power supply connection
• 12Vdc @ 300 mA (.3A) maximum power supply for additional accessories.
• If you lose power to your accessories, the accessories are protected by a poly-fuse. Disconnect
accessories and allow poly-fuse to cool down for 2 minutes before reconnecting.
12Vdc @
300 mA
Power Supply
ALARM
STATUS
DUAL
LINK
GTO LOOP DETECTORS
EXIT SHADOW SAFETY
AT OPEN
LIMIT
PRISON
MODE
+ ACC. PWR.
12VDC
- 300ma
A
C
C.
PO
WER
DU
AL C
ABLE
+12Vdc
COM
DUAL LINK
LINK COM
