31

s Y M P t o M

D i a g N o s i s

c H e c k

Cycle LED ON brightly

Status Light flashes

Cycle terminal shorted to Com

• Push button or key on keypad is

stuck.

• Wire between push button,

keypad, etc. and cycle terminal is

shorted

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Safety LED ON

brightly Status Light

flashes

Safety terminal shorted to Com

• Photo beam or loop detector is

sensing a presence.

• Relay on photo beam or loop

detector is shorted or latched.

• Wire between photo beam

or loop detector and safety

terminal is shorted.

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Shadow LED ON

brightly Status Light

flashes

Shadow terminal shorted to Com

• Photo beam or loop detector is

sensing a presence.

• Relay on photo beam or loop

detector is shorted or latched.

• Wire between photo beam or

loop detector and shadow

terminal is shorted.

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

Open Edge LED ON

brightly Status Light

flashes

Open Edge terminal shorted to Com

• Edge sensor is sensing an

obstruction.

• Relay from edge sensor is

shorted or latched.

• Wire between edge sensor and

open edge terminal is shorted.

• Check terminal voltage with

respect to Com to ensure you

read 12 vdc.

gP-sW050 Visual Feedback
