The system board 35
2 Open the case by following the instructions on page 17. (See “Preventing
static electricity” on page 15.)
3 Locate an available slot and remove the slot cover by removing the screw
that secures it to the back of the chassis.
4 Insert the bottom edge of the expansion card (the keyed edge with the
contacts) into the slot on the system board and push in firmly to seat
the card.
5 After seating the card firmly, use the screw you removed to secure the
card to the rear of the chassis.
6 Connect any cables to the card (see card documentation for proper
jumper settings and cable orientation).
7 Close the case, as described in Chapter 3.
8 Reconnect peripherals, the modem cord, and the power cord, then turn
on the system.
Screw
