Gateway E-5400 - Manual (Page 14)

System board 7
F Voltage regulator module (VRM) for second processor
G ATX power connector
H Supplementary AGP Pro50 power connector
I Auxiliary power connector
J RIMM slots 1 and 2 (Channel A)
K AGP (accelerated graphics processor) slot
L SCSI LED connector
M Diskette drive connector
N Secondary IDE connector
O Primary IDE connector
P Internal speaker
Q Front system fan connector
R Front panel connector
S Front chassis intrusion connector (not used)
T Auxiliary LED connector
U Configuration jumper (J1F2)
V Internal MIDI connector
W Telephony connector
X CD/DVD audio connector
Y PCI slots (5)
Z Battery
AA System fan (not used)
AB Rear chassis intrusion connector
AC Rear system fan
AD RIMM slots 3 and 4 (Channel B)
AE Microphone-in connector
