Persona C30 Card Printer User Guide (Rev. 2.2)
3-6
Installing the Print Ribbon Cartridge (continued)
Step
Procedure
2
a. Remove the liner on the Card Cleaning Roller before installing the Cartridge,
as shown in Display A (upper right arrow of display).
b. Remove the Ribbon securing tape, as shown in Display A (middle right arrow
of display).
3
Slide the Ribbon Cartridge into the Printer, as shown in this section.
4
Raise the front Cover and press the front Cover
’
s black rubber pad or touch pad
to secure it.
Display A
–
Shows the Print Ribbon Cartridge before it is installed or inserted into the Printer.
The Card Cleaning Roller (see arrow) is already inserted into the Print Ribbon Cartridge.
