Chapter 11

CD-RW/DVD-RW Drive Unit (DVDU) Replacement

11-3

11.1

Identifying the Type of CD-RW/DVD-
RW Drive Unit

There are two types of CD-RW/DVD-RW drive units: slot-loading type and tray-
loading type.

FIGURE 11-2

Types of CD-RW/DVD-RW Drive Unit

Note –

The locations of the LED and button might vary depending on the servers.

Note –

When you use the medium on the tray-loading type CD-RW/DVD-RW drive

unit, make sure that the center of the medium is secured to the clamp of the tray, and
then push the tray into the drive.

Location Number

Component

1

Tray-loading CD-RW/DVD-RW drive unit

2

Slot-loading CD-RW/DVD-RW drive unit

1

2
