Page 99
5-19
5.4.6 Color
palette
The color palette lets the user change the color of echoes, background, text and menu as
desired.
R
:
3
** COLOR PALETTE **
TEXT
BKGD
MENU
BKGD3
TEXT
BKGD
MENU
BKGD1
TEXT
BKGD
MENU
DEFAULT SETTING :
NO
YES
(ECHO & BKGD COLORS WILL BE CHANGED.)
G
:
6
B
:
13
ECHO
2
1
3 4 5 6 7 8 9 10 11 12 13 14 15
: SELECT
: CHANGE
MENU: END
Cursor
BKGD2
COLOR :
ECHO 1
Arrow
Figure 5-17 Color palette
1. Press or to place the cursor and arrow on the item to change. Pressing shifts the
arrow and cursor from left to right and top to bottom.
2. Press or to select R(red), G(green) or B(blue) as appropriate.
3. Press or to adjust color.
4. Press the [MENU] key to register your settings and close the menu.
Note:
To restore default color settings, select DEFAULT SETTING, press to select YES, and
press the [MENU] key. A few beeps sound while the default colors are being restored and
then normal operation is restored.
