5-7
5.3.3 Short-cut key
The default settings are key [1], interference rejector; key [2], signal level, and key [3],
background color. The operator may change their functions as desired.
Note:
In the combination modes the short-cut key operation is only possible from the main
window.
1. Select SHORT-CUT following the procedure in paragraph 5.2.1 on page 5-3.
2. Press the [MENU] key to open the menu.
3. Press to select MENU, and then press or to select SHORT-CUT.
: SELECT : CHANGE MENU: END
SELECT FUNCTION TO BE ALLOCATED TO EACH CUSTOM KEY.
CUSTOM KEY MAY BE USED AS A PRESET KEY.
KEY 3
KEY 2
KEY 1
MENU COM1 HORZ VERT ES SHORT-CUT SYS COM2
VER SEARCH VOLUME DEL TRACK AUTO TILT BKGD
SIG LEVEL CLUTTER RES. COLOR WHITE MARKER
VER SEARCH VOLUME DEL TRACK AUTO TILT BKGD
SIG LEVEL CLUTTER RES. COLOR WHITE MARKER
VER SEARCH VOLUME DEL TRACK AUTO TILT BKGD
SIG LEVEL CLUTTER RES. COLOR WHITE MARKER
Figure 5-6 SHORT-CUT menu
4. Press or to select key to preset. For example select KEY 1.
5. Press or to select item.
6. Press the [MENU] key to finish.
Activating a short-cut key
1. Press a CUSTOM MODE key, and the dialog box programmed for the custom key pressed
appears. The dialog box below is for CLUTTER (HORZ).
CLUTTER (HORZ): 0 1 2 3
2. Press or to select option desired
3. Press the [MENU] key to close the dialog box.
