5.4.4 Echo sounder mode range settings
As with the horizontal and vertical fan modes, the user may preset the echo sounder mode’s
ranges.
1. Select RANGE-E/S MODE at the SYS menu and then press .
2
:
20
3
:
30
4
:
40
10
:
200
11
:
250
12
:
300
13
:
400
14
:
500
15
:
600
DEFAULT SETTING :
NO
YES
: SELECT
: CHANGE
MENU: END
1
:
10 (10-600m)
5
:
60
6
:
80
7
:
100
8
:
120
9
:
160
** RANGE-E/S MODE **
Figure 5-15 Range-E/S mode menu
2. Press or to select range number desired.
3. Press or to set range. The setting range depends on the transducer used.
4. To restore default echo sounder mode range settings, select DEFAULT SETTING, press
to select YES and press the [MENU] key.
5. Press the [MENU] key to register settings and close the menu.
