5-4
5.3 Short-cut Menu, Preset Menu
These menus program the CUSTOM MODE keys [1], [2] and [3], and one of the menus appears
according to the setting of CUSTOM KEY on the SYSTEM SETTING 1 menu.
Short-cut key: One-touch activation of corresponding dialog box. This is the default setting.
Preset key: One-touch setup of mode, sector, train, range, tilt and speed controls. Below are
the default settings for PRESET.
CUSTOM MODE
key
Display Mode Sector Train Range (m)* Tilt Speed
Key 1 Expanded Horizontal 240 ° 0 ° 250 30 ° Fast
Key 2 Horizontal 360 ° 0 ° 250 30 ° Fast
Key 3 Vertical Fan 180 ° 90 ° 120 90 ° Fast
* - Default range for 60 kHz transducer. Default range changes with transducer.
5.3.1 Selecting short-cut or preset
1. Press the [MENU] key to open the menu.
2. Press to select MENU, and then press to select SYS.
NO YES
: SELECT : CHANGE MENU: END
GO TO SYS MENU
MENU COM1 HORZ VERT ES PRESET COM2 SYS
Figure 5-2 Display for opening system menu
3. Press to select GO TO SYS MENU.
4. Press to select YES.
