SPECIFICATIONS OF 10.4 INCH COLOR LCD SEARCHLIGHT SONAR
CH-250
1 GENERAL
1.1 Display System 10.4 inch Color LCD
1.2 Transmit Frequency 60, 88 or 150 kHz selected
1.3 Output Power 0.8 kW (60 kHz) to 1.2 kW (150 kHz)
1.4 Range (factory setting)
Detection Range (m)
[H: horizontal mode, V: vertical fan mode]
60 kHz 88 kHz 150 kHz
Range
H V H V H V
1 10 10 10 10 10 10
2 20 20 20 20 20 20
3 40 30 40 30 40 30
4 80 40 80 40 60 40
5 120 60 120 60 80 60
6 160 80 160 80 120 80
7 200 100 200 100 160 100
8 250 120 250 120 200 120
9 300 160 300 160 250 160
10 400 200 400 200 300 200
11 500 250 500 250 400 250
12 600 300 600 300 500 300
13 800 400 800 400 600 400
14 1200 500 1000 500 800 500
15 1600 600 1200 600 1000 600
2 DISPLAY/ CONTROL UNIT
2.1 Display 10.4 inch color LCD, 640 x 480 dots
2.2 Picture Color Echo: 16 or 8 colors (echo)
Back-ground: 3 colors selected (user setting available)
2.3 Display Mode Horizontal (Normal/Expanded), Vertical fan
(Left-right or top-bottom position), Echo sounder
2.4 Combination Display Plotter, Vertical fan, Strata, History
2.5 Alphanumerical Indication Range, Sensitivity, TVG, Tilt angle, Interference rejection
2.6 Data Indication L/L (Own ship or cursor), Depth, Bearing,
Ship’s speed/Water current vector, Track,
Water temperature (External IEC-61162 data required)
