Page 96
5-16
5.4.3 Vertical fan mode range settings
As with the horizontal mode, the user may preset the vertical fan mode’s ranges.
1. Select RANGE-VER MODE at the SYS menu and then press .
2
:
20
3
:
30
4
:
40
10
:
200
11
:
250
12
:
300
13
:
400
14
:
500
15
:
600
DEFAULT SETTING :
NO
YES
: SELECT
: CHANGE
MENU: END
1
:
10 (10-600m)
5
:
60
6
:
80
7
:
100
8
:
120
9
:
160
** RANGE-VER MODE **
Figure 5-14 Range-ver mode menu
2. Press or to select range number desired.
3. Press or to set range.
4. To restore default vertical fan mode range settings, select DEFAULT SETTING, press to
select YES and press the [MENU] key.
5. Press the [MENU] key to register settings and close the menu.
