5-10
SYSTEM SETTING 1 menu
1. Display the SYSTEM menu and press or to select SYSTEM SETTING.
2. Press .
3. Press to MENU.
4. Press to select “1.”
OFF 10sec 30sec 1min 3min 6min
TARGET L/L : OFF ON
CUSTOM KEY : PRESET KEY SHORT-CUT KEY
OFF NORMAL RED
ETA MARK :
EMPHASIS MODE :
m ft fa HIRO P/B UNIT :
OFF FLOW FROM FLOW TO
SHIP'S L/L SHIP'S LOP CURSOR L/L POSITION :
CURRENT DATA :
HEADING INDICATION : TRUE AZ
: SELECT : CHANGE MENU: END
MENU 1 2
NORTH MARK : OFF ON
CSE DATA : NAV GYRO
NAV DATA : GPS LoranC LoranA DR DECCA OTHERS
TVG CORRECTION : OFF 1/2 1/1
** SYSTEM SETTING 1 **
TEMP :
°
C
°
F
TRACK : OFF ON
Figure 5-8 System setting 1 menu
SYSTEM SETTING 1 menu description
POSITION: Chooses how to displays ship’s position; latitude and longitude, Decca/Loran LOP
or Cursor L/L. (The connected navigator must be capable of displaying L/L or LOP.) The default
setting is latitude and longitude. Position data required.
TRACK: Turns the track display on or off on the horizontal display. The track is always shown
on the video plotter display regardless of this setting.
CURRENT DATA: Turns current data (tide) on or off. FLOW FROM shows from what direction
the current is flowing; FLOW TO shows the direction the current is heading. The default setting
is OFF. Requires connection of a current indicator.
Current Vector
FLOW FROM FLOW TO
Figure 5-9 Current vector
