5.4.2 Sonar (horizontal) mode range settings
The user may preset horizontal mode ranges as desired.
1. Select RANGE-SONAR MODE at the SYS menu and then press .
2
:
20
3
:
40
4
:
60
10
:
300
11
:
400
12
:
500
13
:
600
14
:
800
TRACK DISP
:
500 (500-5000m)
15
:
1000
DEFAULT SETTING :
NO
YES
: SELECT
: CHANGE
MENU: END
1
:
10 (10-1600m)
5
:
80
6
:
120
7
:
160
8
:
200
9
:
250
** RANGE-SONAR MODE **
Figure 5-13 Range-sonar mode menu
2. Press or to select range number desired.
3. Press or to set range. The setting range depends on the transducer used. The figure
above shows the default settings for the 60 kHz transducer.
4. To set the range of the video plotter display, press to select TRACK DISP and set range
with or .
5. To restore default horizontal mode range settings, select DEFAULT SETTING, press to
select YES and press the [MENU] key.
6. Press the [MENU] key to register settings and close the menu.
