Furuno CH-250 - Manual (Page 89)

5-9
5.4 SYS Menu
This menu provides items which may be set according to operator’s preference. A
demonstration mode is provided to acquaint you with the many functions of this equipment, and
it may be used without connection of the transducer.
1. Press the [MENU] key to open the menu.
2. Press to select MENU, and then press to select SYS.
3. Press to select GO TO SYS MENU.
4. Press to select YES.
RANGE-SONAR MODE
RANGE-VERTICAL MODE
RANGE-E/S MODE
ADJ MOTION SENSOR
TX FREQ ADJUST
TEST
TEST PATTERN
DEMO MODE
DEFAULT
: SELECT : MENU DISPLAY MENU: END
SYSTEM SETTING :
COLOR PALETTE
LANGUAGE
SYSTEM BACKUP
LOAD BACKUP DATA
HEADING OFFSET, DRAFT OFFSET
** SYSTEM MENU **
RANGE-TRACK MODE
Adjusted at installation.
See installation manual
See Chapter 6.
Figure 5-7 System menu
5. Press or to select item desired.
6. Press or to open corresponding dialog box.
7. Press or to select option.
8. Press the [MENU] key twice to register your selection and close the menu.
