4-4
SPARC Enterprise M3000 Server Service Manual • November 2009
lists the access location and applicable installation methods for each FRU.
Fan unit (FAN_A)
Top
Yes
Yes
†
Yes
†
Fan backplane (FANBP_B)
Top
Yes
No
No
Operator panel (OPNL)
Front/top
Yes
No
No
* The FRU is operated directly, without using XSCF commands.
† The FRU is operated with XSCF commands.
‡
■
The hard disk drive has a redundant configuration only when disk mirroring software is used.
■
If a hard disk drive is an unmirrored boot device, it must be replaced by using the cold replacement procedure. However, if a boot
device can be disconnected by means of a Solaris OS function or disk mirroring software function, active replacement can also be
performed. The procedure for disconnecting a hard disk drive varies depending on the software being used. For details, see the man-
uals for the relevant software.
TABLE 4-3
FRU Access Locations and Installation Methods
FRU
Access
location
Cold addition
Hot addition
Active
addition
Where to find the
procedure
Motherboard unit
(MBU_A, MBU_A_2, MBU_A_3,
MBU_A_4)
Top
No
No
No
Memory (DIMM)
Top
Yes
No
No
PCIe card (PCIe)
Top
Yes
No
No
Hard disk drive (HDD)
Front
Yes
Yes
*
* The FRU is operated directly, without using XSCF commands.
Yes
†
† The FRU is operated with XSCF commands.
Hard disk drive backplane (HDDBP) Top
No
No
No
CD-RW/DVD-RW drive unit
(DVDU)
Front/top
No
No
No
Power supply unit (PSU)
Rear
No
No
No
Fan unit (FAN_A)
Top
No
No
No
Fan backplane (FANBP_B)
Top
No
No
No
Operator panel (OPNL)
Front/top
No
No
No
TABLE 4-2
FRU Access Locations and Replacement Methods (Continued)
FRU
Access
location
Cold
replacement
Hot
replacement
Active
replacement
Where to find the
procedure
