B-2
SPARC Enterprise M3000 Server Service Manual • November 2009
B.2
Motherboard Unit
The motherboard unit is the main circuit board of the M3000 server. The following
components connect to the motherboard unit.
■
■
■
■
Power is supplied from the power supply units to the motherboard unit. To remove
and replace the motherboard unit, power off the server. The replacement work is
performed from the top of the server.
Because the CPU and the XSCF unit are connected directly to the motherboard unit,
neither of them can be replaced individually. There are two types of motherboard
units for the M3000 server: the motherboard unit mounted with the CPU consisting
of two-core processors and the motherboard unit mounted with the CPU consisting
of four-core processors. When replacing a motherboard unit, the replacement unit
must contain the same type of processor. For example, do not replace a motherboard
unit that has two-core processors with one that contains four-core processors.
For the replacement procedure, see
CD-RW/DVD-RW drive
unit (DVDU)
No
Yes
Power supply unit (PSU)
Yes
Yes
Yes
Yes
Fan unit (FAN_A)
Yes
Yes
Yes
Yes
Fan backplane (FANBP_B) No
Yes
Operator panel (OPNL)
No
Yes
*
■
A redundant configuration is created with the hard disk drive only when the disk mirroring software is
used.
■
If a hard disk drive is an unmirrored boot device, it must be replaced by using the cold replacement proce-
dure. However, if a boot device can be disconnected by means of a Solaris OS function or disk mirroring soft-
ware function, active replacement can also be performed. The procedure for disconnecting a hard disk drive
varies depending on the software being used. For details, see the manuals for the relevant software.
TABLE B-1
FRU components (Continued)
Component
Redundant
Cold
replacement
Hot
replacement
Active
replacement
Cold
addition
Hot
addition
Active
addition
