Chapter 5 Internal Components Access 5-3
5.1.2 Sliding the Server into the Equipment Rack
1. Push the server back into the equipment rack.
2. Tighten the two screws at the front of the server to secure it in the equipment
rack ( FIGURE 5-1 ).
3. If the equipment rack is supplied with a Quake-Resistant Options Kit or
stabilizer, return to its original position.
5.2 Removing and Attaching the Top Cover
Caution – All internal components can be replaced in cold replacement mode. The
server must be powered off and the power cord must be disconnected from the
power supply. Before the top cover is removed, the server must be pulled out from
the equipment rack. For the procedure for pulling the server out from the equipment
rack, see
Section 5.1, “Sliding the Server Into and Out of the Equipment Rack” on
page 5-1 .
5.2.1 Removing the Top Cover
Caution – All internal components can be replaced in cold replacement mode. The
server must be powered off and the power cord must be disconnected from the
power supply.
1. Loosen the three screws at the top rear of the server.
