7-8

SPARC Enterprise M3000 Server Service Manual • November 2009

7.3

Removing the DIMMs

1. Pull the DIMM eject levers outward to release the DIMM.

2. Pull the DIMM upwards to remove the DIMM from the socket.

3. Place the DIMM on a conductive mat.

FIGURE 7-4

Removing the DIMMs
