Page 57

KONA Capture, Display, Convert v15.5 57 www.aja.com

Reset to Default

When you click the ‘Reset to default’ button the control panel will delete the

User’s preference file and do one of the following:

• If “Shared” preferences exist, they are reloaded and the device is set to this

state.

• If the “Shared” preferences file does not exist, “factory defaults” are loaded

and the device is set to this state.

Erase all Prefs

For technical support purposes you may be required to remove Preference

settings. This button automates that function. If activated, all your preference

setting will be lost.
For more information on Preset preferences see

Firmware Screen

Use the Firmware link to access the firmware update/changeover screen.
For the KONA 4, the Desired pulldown menu allows you to select either:

• UFC Mode—supports SD, HD, and 2K formats (allows up/down/cross-

conversion).

• 4K Mode—supports SD, HD, 2K, UltraHD (3840x2160) and 4K (4096x2160)

formats (disables up/down/cross-conversion).

For KONA 5 the following firmware versions are available:

• 4K—supports SD, HD, 2K, UltraHD (3840x2160) and 4K (4096x2160) formats.
• 8K Mode—supports the capture or playback of 8K material, as well as lower

bitrate material.

Click

Install

to erase the current firmware and load the desired firmware.

You will be required to power-cycle your computer to finish the changeover.
See

for details.
