Recording 69
Manual (+L) A limiter prevents the signal from clipping if the input signal level combined
with the set gain results in signal levels exceeding -6 dBFS.
Auto Auto matches a 4 dBu input signal to -20 dBFS. This setting leaves enough
headroom for recording and avoids audio clipping. When Auto is selected, au-
dio levels cannot be adjusted by the user.
2. Set channel 1 and 2 control to your preference.
Channel 1/2 Gain
1. Select MENU > Recording > Audio Recording > Ch 1 Gain
Select MENU > Recording > Audio Recording > Ch 2 Gain
2. Using the CLICKWHEEL , adjust the channel gain. The meters show the current level of the channel
signal in dBFS. Additionally audio levels are displayed on the HOME screen as well as the status
info of the viewfinder and the SDI outputs.
Note: Gain setting is only available when audio recording is enabled and channel control is set to either
Manual or Manual (+L) .
Internal Microphones
The internal microphones can be used to record a reference track, sometimes also referred to as
"scratch track". Some software tools can synchronize the master audio to the image using the reference
track. The signal of the internal microphones is recorded to audio channels 3 and 4. The audio
recording level of the internal microphones is fixed, with the left microphone (channel 3) using a +18dB
higher gain than the right microphone in order to cover a wide range of audio levels.
► Select
MENU > Recording > Audio Recording > Internal Microphones
to activate/deactivate recording of the internal microphones.
The microphone icon in the status info of EVF and the SDI outputs indicates active in-
ternal microphones.
Headphones Volume
1. Select MENU > Recording > Audio Recording > Headphone Volume .
2. Adjust the headphones' volume to your preference.
Test Tone
The camera can output a 1 kHz sine test tone on all recording channels, on headphones out and the
SDI outputs.
► Select
MENU > Recording > Audio Recording > Test Tone .
Following options are available:
Off
-9 dBFS
-18 dBFS
-20 dBFS
Note: Test tone can only be activated when audio recording is enabled.
