5-1
ENGINE & ATTACHING PARTS
(9114-5132 & 9115-5040) Engine Left Side View
534C-9 Starting Serial No. 0444003
534C-10 Starting Serial No. 0266107
Original Issue 8-97
Revised 9-29-99
Item
Part No.
Qty.
Description Of Part
36
9116-1310
1
THROTTLE BAR
37
8859-1206
1
O-RING
38
9002-7187
3
TY-RAP
39
8820-1020
2
HEX HD CAPSCREW, 5/16-18X1,
GR5
40
2486-1170
2
SUPPORT CLAMP
41
8594-1017
2
SUPPORT CLAMP
42
8850-1005
2
HEX NUT, 5/16-18
43
7713-3447
1
HOSE ASSY
44
9108-3306
1
CONNECTOR (includes item 37)
45
9020-5792
1
CUSHION CLAMP
46
9114-6021
1
L.H. ENGINE MOUNT
47
8855-1010
2
LOCKWASHER, 5/16
48
9114-3183
1
TUBE ASSY
49
8688-3106
3
HOSE CLAMP
50
8698-3649
1
ELBOW, 90 DEGREES, 1/4 PIPE
51
8820-1075
1
HEX HD CAPSCREW, 1/2-13X3-1/2,
GR5
52
8026-3012
2
WHIZ LOC SCREW, 1/4-20X1/2
53
9114-6101
1
DIPSTICK WELDMENT
54
9002-7473
2
HARDENED WASHER, 3/4
55
9114-3030
1
SHOCK MOUNT
56
9114-3131
1
HEX HD CAPSCREW, M12X1.25X90
57
8852-1008
1
LOCKNUT,1/2-13
58
8856-1111
1
FLAT WASHER, 1/2
59
9114-3032
1
REBOUND WASHER
60
9114-3031
1
SHOCK MOUNT
61
Ref
HYD PUMP (see page 10-19
for details)
62
8866-2019
1
STR THD CONNECTOR
63
8319-1040
2
SOC HD CAPSCREW, M10X1.5X30
64
8319-1013
2
LOCKWASHER, M10
65
8667-1112
1
GASKET
66
9114-3176
1
STR THD CONNECTOR
67
9114-3184
1
HOSE
68
8063-3030
1
HOSE CLAMP
69
9114-3013
1
PUMP MOUNT FLYWHEEL
COUPLING (includes the following)
70
9002-8695
3
BAND CLAMP
71
9114-3185
1
HOSE ASSY
72
8821-1068
8
SOC HD CAPSCREW, 3/8-16X5/8
73
8855-1011
8
LOCKWASHER, 3/8
74
8820-1112
2
HEX HD CAPSCRREW, 3/8-16X5/8,
GR5
75
9112-4125
1
DIPSTICK
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE FOR
SERVICE.
Item
Part No.
Qty.
Description Of Part
9114-5132
Ref
ENGINE ASSY (534C-9) (includes
items 1 thru 49 & 61 thru 68 on page
5-1 and all items on page 5-2)
9115-5040
Ref
ENGINE ASSY (534C-10) (includes
items 1 thru 49 & 61 thru 68 on page
5-1 and all items on page 5-2)
1
1
B3. 9C-110 EPA ENGINE (C-9)
1
B3. 9C-116 EPA ENGINE (C-10)
2
9114-3329
1
FAN ASSY
3
9116-3122
1
TUBE ASSY
4
8471-2738
2
SPLIT FLANGE CLAMP
5
8320-1135
4
HEX HD CAPSCREW, 7/16X14-1 1/2,
GR8
6
8855-1012
8
LOCKWASHER, 7/16
7
Ref
MAIN PUMP (see page 10-17
for details)
8
8820-1095
2
HEX HD CAPSCREW, 5/8-11X1-1/2,
GR5
9
8319-1010
10
LOCKWASHER, M12
10
8866-2239
1
SWIVEL NUT RUN TEE, 3/8 TUBE
11
8859-1027
1
O-RING
12
9114-3121
1
SUCTION TUBE
13
8471-1334
2
FLANGE CLAMP
14
9114-6056
1
R.H.ENGINE MOUNT
15
8319-1032
8
HEX HD CAPSCREW, M12X1.75X35
(lubricate and torque to 58-68 ft.lbs.)
16
9116-3260
1
ACCELERATOR CABLE
17
9116-1313
1
THROTTLE BRACKET
18
8319-1004
2
HEX HD CAPSCREW, M12X1.75X30
19
8319-1012
2
LOCKWASHER, M6
20
8319-1035
2
SOCKET HD CAPSCREW,
M6X1.00X16
21
9114-3345
1
BALL SOCKET
22
9114-3344
1
OVER TRAVEL
23
9114-3302
1
WIRING HARNESS
24
119” FUEL HOSE, 5/16
25
8820-1051
4
HEX HD CAPSCREW, 7/16-14X1-1/4,
GR5
26
9003-0271
1
HOSE NIPPLE
27
9108-3106
1
O-RING
28
2474-1047
1
PRESSURE SWITCH
29
9114-3315
1
OIL PRESSURE SENDER
30
9108-1388
1
TAPPED BAR
31
8319-1041
4
HEX HD CAPSCREW, M8X1.25X70
32
8688-3075
2
TUBE FITTING
33
28”
NYLON TUBE
34
8856-1108
4
WASHER, 5/16
35
9002-7472
2
HARDENED WASHER, 5/8
KG
* Added item 75.
*
