CHASSIS & ATTACHING PARTS
Rear Axle & Attaching Parts
Starting Serial No. 0344001
Starting Serial No.0266001
Original Issue 9-94
Revised 3-1-99
2-2
NOTE #1: Cylinder base end must be free to rotate. Shim steer cylinder base end as
required to maintain a total max. gap of 1/16".
NOTE #2: Shim bottom knuckles as required to maintain no more than 1/32" movement. Shim top knuckles as
required to maintain no more than 1/16" gap. Must have a minimum of one shim.
NOTE #3: See option section for details on the Rear Axle Rework Kit and the Rear Axle Advantage Kit.
NOTE #4: All machines need to bore Steering Knuckles to use items 25 & 60. See diagram on previous page. Unless
you have purchased new Steering Knuckles part number, 9112-0003 & 9112-0004.
NOTE #5: You may have to use item 32 & 59 in place of items 61 & 62, unless you have purchased new Steering
Knuckles part number, 9112-0003 & 9112-0004. See engineering print that comes with the Steering Knuckle Kit for
details.
PCN 980730 MPC 3459-JH * Revised parts list, service notes and illustration.
Item Part No. Qty. Description Of Part
9103-5240 1 STEERING KNUCKLE KIT, (includes
items 23 thru 26, 28 thru 32, 35, 36,
40 thru 51, 60 & 61 one kit does both
sides)
9104-5152 AR STEERING CYLINDER PIN KIT,
(includes one each of items 22 thru
27, 33, & 34, one kit needed for each
side)
1 Ref DRIVE HUB, (see page 6-8 for
details)
2 9112-0004 1 R.H. STEERING KNUCKLE, (see
note #4)
3 8821-2321 2 SLOT HD CAPSCREW, 5/8-11X3-3/4,
GR8
4 9104-3222 4 CAPSCREW 12PT, 3/4-10X2,
(torque to 270-290 ft.lbs.)
5 8320-1006 12 HEX HD CAPSCREW, 5/8-10X2
6 9104-3247 2 SELF-ALIGNING BUSHING
7 8668-1572 12 HARDENED WASHER, 3/4
8 9114-6009 1 REAR AXLE WELDMENT, (includes
items 30, 46, & 55)
9 9108-1177 1 REAR AXLE MOUNTING PIN
10 9002-0247 1 HEX HD CAPSCREW, 1-1/4-7X6
11 9103-1009 1 SHIM, (1/4 thick)
12 8510-1098 1 HEX NUT, 1-1/4-7
13 8850-1006 2 HEX NUT, 3/8-16
14 8855-1011 2 LOCK WASHER, 3/8
15 8320-1144 2 HEX HD CAPSCREW, 3/8-16X5-3/4,
GR5
16 8867-1001 4 LUBE FITTING, STRAIGHT, 1/8
17 9108-1695 2 STEERING CYLINDER PIVOT PIN
18 8867-1033 4 LUBE FITTING, STRAIGHT, 1/4-28
19 9104-1598 2 SHIM, (.060 thick, see note #1)
20 Ref STEERING CYLINDER ASSY, (see
page 10-6 for details)
21 9020-1918 2 SHIM, (10 gauge, see note #1)
22 8852-1312 2 HEX LOCK NUT, 3/4-10, (torque to
160-175 ft. lbs.)
23 9108-1415 2 DIRT SHIELD
24 9104-1438 2 SPACER, (3/16 thick)
9104-1732 2 SPACER, (3/16 thick)
25 9112-1240 4 BUSHING, (see note #4)
26 8859-1019 2 O-RING
Item Part No. Qty. Description Of Part
27 9104-1481 2 STEERING CYLINDER PIN
28 9112-3030 4 BACK-UP RING
29 8859-1032 4 O-RING
30 9112-3028 2 BUSHING
31 8692-1268 2 LIP SEAL
32 8821-1117 2 SOCKET HD CAPSCREW,
5/8-11X3-3/4, (see note #5)
33 9104-1459 2 WASHER
34 8850-1416 2 HEX JAM NUT, 1-14, (torque to
225-250 ft. lbs.)
35 8867-1022 4 LUBE FITTING, 30 DEGREES, 1/8
36 9108-1693 2 UPPER KING PIN
37 9104-1439 2 TIE ROD PIN
38 8320-1140 2 HEX HD CAPSCREW, 3/8-16X2-3/4,
GR8
39 8852-1306 2 LOCK NUT, 3/8-16
40 8858-1323 4 RETAINING RING
41 9114-1424 2 LOWER KING PIN
42 9104-1596 4 SHIM, (20 gauge, see note #2)
43 9104-1449 4 SHIM, (.060 thick, see note #2)
44 9104-1450 4 SHIM, (.0478 thick, see note #2)
45 9104-1451 6 SHIM, (.106 thick, see note #2)
46 9112-3027 2 BUSHING
47 9112-3029 2 O-RING
48 8821-2321 2 SLOT HD CAPSCREW, 5/8-11X3-3/4,
GR8
49 8855-1153 2 LOCK WASHER, 5/8
50 8859-1104 4 O-RING
51 9112-1091 2 THRUST BUSHING
52 9112-0003 1 L.H. STEERING KNUCKLE, (see note
#4)
53 9116-6063 1 TIE ROD, (includes item 6)
54 2460-1570 2 LIP SEAL
55 9112-3031 2 BUSHING
56 8850-1110 2 HEX NUT, 5/8-11
57 9108-1691 1 SHIM, (.1046 thick)
58 9020-6846 1 SHIM, (.1345 thick)
59 8855-1109 2 LOCKWASHER, 1/2, (see note #5)
60 9112-1239 2 BUSHING, (see note #4)
61 8821-1121 2 SOCKET HD CAPSCREW,
5/8-11X3-3/4, GR8, (see note #5)
62 8852-1208 2 HEX LOCKNUT, 1/2-13, (see note #5) *
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
*
