Gradall 534C-10 Parts Manual - Manual (Page 45)

KG 3-6
BOOM
Boom Cross Section /Push Beam Pin
Starting Serial No. 0344001
Starting Serial No. 0266001
Original Issue 1-96
Revised 5-4-98
A
A
9114-1128
PUSH BEAM PIN
(qty. 2)
8820-1075
HHCS, 1/2-13X3-1/2, GR5
(qty. 2)
8855-1013
LOCKWASHER, 1/2
(qty. 2)
B C D
B C D
VIEW A-A VIEW B-B VIEW C-C VIEW D-D
* Added hardware used to mount push beam pins.
