Gradall 534C-10 Parts Manual User Manual
Page 172
KG
Item
Part No.
Qty.
Description Of Part
9114-5129
1
HYDRAULIC RESERVOIR ASSY
(includes all items)
1
9114-3133
1
HYDRAULIC OIL TANK
(includes item 30)
2
9108-3070
1
FLUID LEVEL GAUGE
(includes items 3 & 4)
3
2
SCREW
4
2
WASHER
5
9114-3172
2
MINI CHECK COUPLING
6
9114-1222
1
BRACKET
7
8866-1084
1
BULKHEAD UNION, 9/16-18X3/8
TUBE
8
8866-2105
1
ELBOW, 90 DEGREES (swivel nut)
9
9002-7179
1
BULKHEAD UNION, 90 DEGREES
10
9114-3061
1
TUBE ASSY
11
9114-3135
1
RETURN FILTER (includes one of
item 13 and item 14)
12
9114-3160
1
SUCTION FILTER (includes one of
item 13)
13
9114-3144
2
FILTER ELEMENT
14
9108-4022
1
COLOR CODED GAUGE
15
9108-3241
1
ELBOW, 90 DEGREES
16
9114-3086
1
ADAPTER, 90 DEGREES
17
8820-1036
4
HEX HD CAPSCREW, 3/8-16X1-1/4,
GR5
18
8856-1004
8
WASHER, 3/8
19
8820-1016
2
HEX HD CAPSCREW, 5/16-18X1/2,
GR5
20
8820-1020
4
HEX HD CAPSCREW, 5/16-18X1,
GR5
21
8856-1005
6
WASHER, 1/2
22
8856-1003
4
WASHER, 5/16
23
9114-1145
2
FILTER SUPPORT
24
9108-3069
1
FILLER BREATHER
25
8855-1011
4
LOCKWASHER, 3/8
26
8850-1006
4
HEX NUT, 3/8-16
27
8866-1013
1
MALE CONNECTOR
28
9114-3178
1
TANK FILTER
29
9114-3179
1
STRAIGHT CONNECTOR
30
1
PLUG
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
HYDRAULIC COMPONENTS
(9114-5129) Hydraulic Reservoir & Filters
Starting Serial No. 0344001
Starting Serial No.0266001
Original Issue 9-94
Revised 5-28-96
10-15
* Changed art on item 13.
