OPTIONAL EQUIPMENT
(9114-5100) Deluxe Light Package
Starting Serial No. 0444003
Original Issue 8-97
Revised 10-6-00
NOTE:
INSTALL CONNECTORS TO TURN SIGNAL
SWITCH AS FOLLOWS - BULLET CONNECTORS:
RED, GREEN, GRAY, BLACK & GRAY/BLACK.
CONNECT YELLOW WIRE ON SWITCH TO
YELLOW WIRE ON PIGTAIL.
ON PIGTAIL SNIP WHITE WIRE AT YELLOW
WIRE AND CONNECT WHITE WIRE TO BLUE
WIRE FROM SWITCH.
ON PIGTAIL REMOVE IN-LINE FUSE FROM
BROWN WIRE AND INSTALL CONNECTOR.
A
A
TO LIGHT SWITCH
(FOR CAB LIGHTS)
TO FUSE FROM IGNITION SWITCH
(FOR DOME LIGHT)
1
3
5
12
1
2
5
12
15
16
17
18
23
15
16
17
18
23
6
7
8
14
13
20
19
21
22
9
10
11
24
25
11
1
4
5
12
15
16
17
18
23
13
53
5
17
23
73
18
23
47
18
23
47
42
41
43
54
31
44
46
FOR R.H. LIGHT ASS'Y
TERMINAL A = GREEN 3B
TERMINAL B = BLACK
TERMINAL C = RED/BLACK
FOR L.H. LIGHT ASS'Y
TERMINAL A = GREEN 3C
TERMINAL B = BLACK
TERMINAL C = GRAY/RED
C
A B
C
A B
AUX VIEW A-A
FOR CAB ENCLOSURE
EQUIPPED MACHINES ONLY!
