ATTACHMENTS
(9055-3011) 180 Degree Swing Frame
Starting Serial No. 0344001
Starting Serial No. 0266001
Original Issue 3-95
4-13
KG
Item
Part No.
Qty.
Description Of Part
9055-3011
1
SWING FRAME ASSY, 180 DEGREE,
(includes all items)
9114-4203
Ref
HOSE KIT, (includes items 34, 43, 45,
46, 47, 64 & 66)
1
9114-4204
1
FORK BASE WELDMENT
2
9114-4205
1
FORK PIN
3
9114-4206
2
HEX NUT, 1/2
4
9120-4400
2
LOCKWASHER, 1/2
5
9114-4207
2
COLLAR
6
9114-4208
2
HEX HD CAPSCREW, 1/2X3-1/4,
GR5
7
9114-4209
8
SNAP RING
8
9114-4210
4
PIN
9
9114-4211
1
HEAVY HEX JAM NUT, 3/4
10
9114-4212
1
HEX HD CAPSCREW, 3/4X2, GR5
11
9104-4251
1
SHAFT
12
9104-4242
2
PIN RETAINER
13
9120-4368
4
LOCKWASHER, 5/8
14
9114-4213
4
HEX HD CAPSCREW, 5/8X1-1/4,
GR5
15
9104-4243
1
INTERMEDIATE FRAME
16
9104-4244
4
BRONZE BUSHING
17
9104-4245
AR
SHIM
18
9114-4214
10
LUBE FITTING, STRAIGHT, 1/4
19
9114-4215
2
HEX HD CAPSCREW, 1/4X3/4, GR5
20
9114-4216
2
LOCKWASHER, 1/4
21
9114-4217
2
ACTUATOR LEAF
22
9114-4218
2
SHIM ACTUATOR
23
9114-4219
1
FLAT HD CAPSCREW, 2X1/4
24
9104-4249
2
THRUST BEARING
25
9104-4250
2
LUBRICATION COLLAR
26
9104-4241
1
SHAFT
27
9114-4220
1
FIXED FRAME
28
9114-1350
2
PIN
29
9114-4221
4
SOCKET SET SCREW, (cup point),
1/4X3/8
30
9114-6053
1
PIN SUPPORT, L.H.
9114-6054
1
PIN SUPPORT, R.H.
31
9104-3126
1
DUST CAP, FEMALE
32
9020-4245
1
QUICK DISCONNECT HYDRAULIC
FITTING, FEMALE
33
8866-1013
2
STRAIGHT FITTING
34
9114-4222
1
HOSE ASSY
35
9120-4563
2
ELBOW, 90 DEGREES, (includes
item 36)
36
2
O-RING
37
9114-4223
2
HEX HD CAPSCREW, 5/16X3, GR5
38
Ref
SWING VALVE ASSY, (see page
13-18 for details)
39
9114-4224
4
LOCKWASHER, 5/16
Item
Part No.
Qty.
Description Of Part
40
9114-4225
2
HEX NUT, 5/16
41
8866-2064
4
ELBOW, 90 DEGREES, (includes
item 42)
42
8859-1204
6
O-RING
43
9114-4226
1
HOSE ASSY
44
9114-4227
1
ELBOW, (swivel nut)
45
9114-4228
1
HOSE ASSY
46
9114-4229
1
HOSE ASSY
47
9114-4230
2
HOSE ASSY
48
9104-4262
2
CYLINDER ASSY, (includes items 50
thru 60)
49
9114-4231
AR
CYLINDER SEAL KIT, (includes items
51, 52, 56, 57, 58 & 60)
50
9114-4232
1
TUBE ASSY
51
1
PIP RING
52
1
PISTON SEAL
53
9114-4233
1
LOCKING SET SCREW
54
9114-4234
1
PISTON
55
9114-4235
1
ROD ASSY
56
1
O-RING
57
1
BACK-UP RING
58
1
ROD SEAL
59
9114-4236
1
GLAND
60
1
ROD WIPER
61
9114-4237
4
SPERICAL BEARING
62
9104-3125
1
DUST CAP, MALE
63
9020-4244
1
QUICK DISCONNECT HYDRAULIC
FITTING, MALE
64
9114-4238
1
HOSE ASSY
65
9114-4239
2
HEX HD CAPSCREW, 5/16X3-1/4,
GR5
66
9114-4240
1
HOSE ASSY
67
8697-1355
2
ELBOW, 90 DEGREES, LONG,
(includes item 42)
68
2
CHAIN CONNECTION
69
9114-4241
1
CHAIN, 18"
70
9114-4242
2
DETENT PIN
71
9114-4243
1
LOCK-LINK ASSY, (includes items
72 thru 75)
72
9114-4244
1
CHAIN, 7"
73
9114-4245
1
LOCK-LINK WELDMENT
74
9114-4246
1
CLEVIS
75
9114-4247
1
DETENT PIN
76
8866-2062
6
ELBOW, 90 DEGREES, (includes
item 77)
77
8859-1203
6
O-RING
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
