65k-2gjr spinner assembly, 77 drawings – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 10 to 20 User Manual
Page 77
65K-2GJR Spinner Assembly
77
Drawings
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
24703-JR Case, Moving Arm Assembly
2
4
95601A435 Fiber Washer
3
1
24710-JR Case, Stationary Arm Assembly
4
3
24722 Spacer, Gear Box
5
1
24CYL25-AS Grip Cylinder, Top
See Explosion
6
4
98404A999_1x5 11.16 QK Pin
7
2
24637 Bushing
8
2
24729 Flanged Bearing
9
4
24646 Wear Block
10
1
24701 Mounting Plate, Gear Box
11
1
24625 Reducer Assembly
See Explosion
12
3
807603 1.4 NPT Plug Hp
13
1
24642 Key, Drive Sprocket
14
1
24641 Drive Sprocket
15
1
24635 Spacer, Drive Sprocket
16
1
24702 Mounting Plate, Bearing
17
1
24656 Flange Bearing, Modified
18
1
24658 Chain Guard
19
2
806452_5.8-11 x 9.00 lg. Hex Bolt
20
1
806450-1_5.8-11 x 7.00 lg. Hex Bolt Grd. 9
21
5
810732_5.8 Lock Washer
22
2
806416_5.8-11 Hex Nut
23
2
806435_5.8-11 x 1.50 lg. Hex Bolt
24
4
810645_3.8 Lock Washer
25
4
806025_3.8-16 x 1.50 lg. Hex Bolt
26
1
ME09 Hydraulic Motor Assembly, Manual
27
1
M21 Key
28
1
M22 Motor Mount Gasket
29
1
R25 Sun Gear Kit
30
8
810703_1.2 Lock Washer
31
4
806267_1.2-13 x 1.50lg. Hex Bolt
32
2
24623 Roller Sprocket
33
4
24643 Key, Roller
34
4
24649 Roller
35
4
RST-275-S Retainer Ring
36
2
24CHAIN Chain
37
4
24654 Bearing Seal Assembly
38
4
24731 Sphere-Rol Bearing
39
4
24622 Bearing Cap
40
20
91074A033 Lock Washer Assembly, 1.2
41
20
806373_1.2-20 x 2.00 lg.Hex Bolt Grd. 9
42
8
811150_#14 Brass Washer
43
8
805834_1.4-20 x .50 lg. Hex Bolt
44
2
98404A878 Quick Release Pin
45
1
91268A935_1.0-8 x 9.50 lg. Hex Bolt
46
2
91074A038 Lock Washer Assembly, 1.0
47
1
806580_1.0-8 Lock Nut
48
1
DV Spinner Motor Valve Assembly, JR
See Explosion
49
3
805920 5.16-18 x 1.5 Bolt
50
3
810616_5.16 Lock Washer
51
9
1103K1 Grease Fitting, Straight
52
1
25726 Chain Oiler Assy
See Explosion
53
4
806251_1.2-13 x 1.25 Hex Bolt
54
4
2081-8-6S 1.2 X 3.8 HP Hex Bushing
55
5
2089-6-6S_6MNPT x 6FNPT Fitting 90 Elbow
56
2
2090-6-6S NPT 3.8 Tee Elbow
57
4
810589_1.4 Flat Washer
58
5
810587_1.4 Lock Washer
59
4
805842_1.4-20 x .75 lg. Hex Bolt
60
2
2024-12-8S 12 MNPT X 8MJIC 90 Drg
61
2
2046-8-8S 1.2 HS Swivel Coupling FXF
62
1
805867 1.4-20 X 1 1.2 Hex Tap SS
63
1
805780 1.4-20 Hex Nut SS
64
2
2083-6-6S 3.8 Hex Nipple
65
2
2021-6-6S 6MNPTX6MJIC Fitting Str
66
2
2047-6-6S 3.8 HP 90 Drg ST EL HS SWIL FXM
67
1
24723 Rubber Cover
68
2
2061-10-8S_10MORB x 8MJIC Fitting 45
69
1
24CYL25-BS Grip Cylinder, Bottom
See Explosion
70
1
JHOS-2-54_-8FJICx1.2MNPT Hose33.00 Lg. Hose
71
1
JHOS-1-53_-8FJICx1.2MNPT Hose33.00 Lg. Hose
72
1
30142 Pipe Adjust Position Label
73
4
807801_ Pop Rivet
74
1
30421 Label, Bracket
