Changing the Heel Dies (cont.)
7. Make sure the back and sides of
the new Die are clean.
8. Grease the back of the new Die.
9. Insert the new Die into the Die
Holder (DH) with the teeth of the
Die facing out.
10. Place the Die Holder (DH) back
in the Die Pivot Block (DB).
11. Insert the Heel Die Pin (P).
12. Replace the Heel Die Rollers
(R).
13. Replace the Roller Bushings
(RB).
14. Use the 3/4" wrench to replace the
Heel Die Roller Bolts (B) and
Lock Washers.
Maintenance & Repair 39
Maintenance
& Repair
Part Name Part #
Die Roller Bolt (B) 999-806303
Die Holder Bolt Washers 999-810703
Die Roller (R) 061-20210
Roller Bushing (RB) 061-20208A
Die (D) 061-20194
Die Holder (DH) 061-30031
Part Numbers
