65k-2gjr hydraulic pipe clamp assy – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 10 to 20 User Manual
Page 151
65K-2GJR Hydraulic Pipe Clamp Assy
151
Drawings
ITEM QTY.
PART NO./DESCRIPTION
DESTINATION
COMMENTS
1
1
30008-32 Arm Mount Plate Wldmnt
2
1
30008-27 Rod Clevis Wldmnt
3
1
30008-19 Hook Assembly Wldmnt
4
2
20210 Roller Assembly
5
2
20229A Linkage Nut, Modified
6
2
146 Thrust Bearing Assembly
7
1
20029-1 Washer
8
2
PRP568-230 O Ring
9
2
20208 Spacer Bushing, Roller
10
2
20045A-6 Bolt, Roller Assy 1.5-13 x 2.75
11
2
807493-250 Cotter Pin
12
2
807493-125 Cotter Pin SST
13
2
810703_1.2 Lock Washer
14
2
203102-6-6S T Fitting
15
2
2062-8-6S_6MORB x 4MJIC Fitting 90
16
2
1103K1 Grease Fitting, Straight
17
1
808265_ 1.4-28 x .375 lg. Soc. Hd. Set Screw, Cup Point
18
1
806539_3.4-16 x 3.00 lg.Hex Bolt Grd. 9
19
1
806523_3.4-16 Flex Nut (31FK1216)
20
1
JHOS-10-17 6FJICx-6FJICx35.00lg. Hose
Mid. Grip Cyl. Cap Side
21
1
JHOS-9-18 6FJICx-6FJICx41.00lg. Hose
Mid. Grip Cyl. Rod Side
22
1
HV50R2NA Cylinder, JR
