1. Make sure the nut lock (NL) is in
the unlocked position.
Adjusting the Wrenches
Adjust for Make Up
Adjusting the Nut Lock Detent Setting
(If Needed)
A. Loosen the jam nut (J) to allow
some space for the arm to adjust.
B. Screw the arm (A) in or out to
adjust the stiffness of the
springloaded detent (SD).
C. Tighten the jam nut (J) to secure
the arm (A) from loosening.
A
J
SD
NL
Part Number
Part Name Part #
Adjust Nut Locking System 061-30280
15 Operation
Operation
Continued on next page.
