65k-2gjr middle wrench assembly, 73 drawings – Hawk Industries Hawkjaw Jr. Manual 65K-2GJR Serial Numbers 10 to 20 User Manual
Page 73
65K-2GJR Middle Wrench Assembly
73
Drawings
ITEM
QTY.
PART NO./DESCRIPTION
COMMENTS
1
1
30004A-2A Jaw Plate Assy
2
2
30029 Pivot Sleeve
3
2
30030 Pivot Pin
4
1
30035 Adjust Nut Assy
5
1
30002 Hook Assembly
6
1
30034 Index, Nut
7
1
30007 Spacer, Nut Retainer
8
1
30061 Clip, Nut Retainer
9
2
30009 Torque Arm
10
1
30013-1 Clevis Plate, Midd. Hook, Pin Assy
11
1
30013-2 Clevis Plate, Midd. Hook, Thread
12
3
91074A035 Lock W asher Assy.5.8
13
3
806442 5.8-11 X 3.50 Lg Hex Bolt
14
3
807801_ Pop Rivet
15
7
91074A036 Lock W asher Assembly, 3.4
16
4
806538-2 3.4-16 X 2.50 Lg Hex Bolt
17
6
1103K3 Grease Fitting, 90 Degree
18
1
91074A038 Lock W asher Assembly, 1.0
19
1
806630_1.00-12 x 6.00lg. Hex Bolt
20
2
806594-500_1-14 Lock Nut
21
2
806544_3.4-16 x 5.50 lg. Hex Bolt Grd. 9
22
1
30056A Shoulder Bolt
23
2
806523_3.4-16 Flex Nut (31FK1216)
24
1
92384A092 Push Button Pin
25
1
30005A-2 Die Pivot Block Assy
26
1
30055 Nut Retainer
27
1
806449_5.8-11 x 5.95lg. Hex Bolt
28
1
30062 Spacer, Middle W rench
29
1
30289-1 Lock Plate, Top
30
1
30289-2 Lock Plate, Btm
31
1
30114 Bolt, W rench
32
2
30116 Bolt, W rench
33
1
806646_1.1.4-12 Flex Lock Nut 31FK-2012
34
2
806414-500_5.8-11 Flex Nut (31FA1011)
35
1
65K-2GJR Adjust Nut Locking Assembly, JR
See Explosion
36
6
1103K1 Grease Fitting, Straight
37
1
808413_1.2-13 x .75 lg. Soc. Hd. Cap Screw
38
1
J26 Grip Cylinder
See Explosion
39
2
2062-6-6S_6MORB x 6MJIC Fitting 90
40
1
81036 5.8 Flat W asher
41
1
98404A875_7.625 Lg.Quick Release Pin Assembly
42
2
1103K2 Grease Fitting, 45 Degree
43
1
30057 Pipe Stop Roller
44
1
30063 Bolt, Roller Spindle Modified
45
3
806004_3.8-16 x .75 Lg. Hex Bolt
46
1
98335A114 Hair Pin Retainer
47
1
30038-2MB Link, W rench Mount Assembly
48
12
PRP568-230 O Ring
49
11
146 Thrust Bearing Assembly
50
4
30043-2 Arm Bolt
51
1
30042-1 Link, W rench-Bottom Assembly
52
2
30043-3 Arm Bolt
53
1
30038-1MT Link, W rench Mount Assembly
54
1
30042-2 Link, W rench-Top Assembly
55
1
65K-2GJR Middle Hook Die Holder Assembly
See Explosion
56
1
65K-2GJR Middle Heel Die Holder Assembly
See Explosion
57
1
810703_1.2 Lock W asher
58
3
810645_3.8 Lock W asher
59
1
30004A-2B Jaw Plate Assy
60
6
20029-138AM W asher Assembly
61
2
30029-1 Pivot Sleeve Keeper
62
1
SL5 Danger Label
63
4
807800_ Pop Rivet
64
2
30420 Castle Nut, Modified
65
2
807493-250 Cotter Pin
66
4
30145 Linkage Jam Nut
67
1
30230-2 Clevis Bumper W ldmnt
68
1
30230-1 Bumper
69
4
810705_1.2 Flat W asher
70
4
806221_1.2-13 Flex Nut
71
1
806450-1_5.8-11 x 7.00 lg. Hex Bolt Grd. 9
72
1
30053 Pin, Torque Cyl
