65K-2GJR Spinner Manifold
115
Drawings
ITEM QTY.
PART NO./DESCRIPTION
DESTINATION
COMMENTS
1
1
J2 Spinner Manifold, JR
2
1
SV1 Sequence Valve
3
1
SV3 Differential Valve
4
1
SV2 Spinner Neeble Valve
5
2
206209-8-8S_8MORB x 8MJIC Fitting 90 Ext.
6
2
202702-6-6S_-6MORB x -6MJIC Str. Adaptor
7
2
2062-8-8S 8MORBX8MJIC Fitting 90
8
1
JHOS-5-41 6FJICx-6FJICx26.00Lg. Hose
Bottom Spin Cyl. Rod Side
Port P4
9
1
JHOS-6-42 6FJICx-6FJICx29.00lg. Hose
Bottom Spin Cyl. Cap Side
Port P3
10
1
JHOS-26-40_-8FJICx-8FJICx60 Lg. Hose
Main Man. Port P13
Port P1
11
1
JHOS-25-39_-8FJICx-8FJICx60 Lg. Hose
Main Man. Port P14
Port P2
12
1
HOS-26_-8FJICx-8FJICx26.00lg. Hose
Spinner Shift Valve (IN)
Port P6
13
1
HOS-27_-8FJICx-8FJICx33.00lg. Hose
Spinner Shift Valve (OUT)
Port P5
