eServer Setup and Site Installation Instructions
Page 82 © Mass Electronics Pty Ltd 2009 Edition 5.0 dated 07/01/2014
Figure 4-11: Example Device Properties for Connection 1, Device 1
4-2.6 Set iComm Connection Properties
Once your iComm Server Settings are correct, select each Device and check the internal Device
Settings correspond correctly with the iComm Server, as illustrated below in Figure 4-11, Figure 4-12
and Figure 4-13.
Figure 4-12: Example Device Properties for Connection 2, Device 1
Figure 4-13: Validate your Device Settings with the iComm Server
You can import devices and points to an iComm Server in the Points Manager. Right click on the iComm Server and
select Import Points to locate and import from a valid Genesis or MAXIM configuration file.
NOTE
The most cricital item on this window is the Remote Device Name Field, which uses the format [iComm Server
Connection ID]:[Device ID]. So for a device at address 1 on iComm connection 1, its correct Remote Device Name
Field would be 1:1
IMPORTANT
