Chapter 2 Using Chromatogram and Spectrum Windows
2-28
Applied Biosystems
2
2.4.9 Annotating Traces
You can add text annotation to traces by:
•
Copying a line of results from the Output window (or
copying any ASCII text from any source), then pasting
the copied information on the trace
•
Typing text on the trace
Copying results
To copy results:
1.
Generate results as desired by selecting commands
from the Tools or Applications menu. For more
information, see:
• Section 5.3, Manual Calibration, or Section 5.4,
• Section 5.6, Mass Deconvolution (Mariner Data
• Section 6.2, Using the Isotope Calculator
• Section 6.4, Using the Signal-to-Noise Ratio
2.
Click the Results tab in the Output window.
3.
Select the line of text to copy, then right-click and select
Copy from the menu displayed.
NOTE: If you select more than one line of text, only the
first line is pasted when you annotate the trace.
