44 HP E1459A SCPI Command Reference
DISPlay:MONitor:PORT? [MINimum | MAXimum | DEFault]
Returns the number of the current display Port as +0, +1, +2, or +3.
Parameters None
Comments •
When sent with no parameter, this query returns a decimal number indicating
the Port being monitored. If AUTO was selected as the Port parameter in the
DISP:MON:PORT <port> command, the query returns the number of the most
recently-viewed Port. If either MINimum or DEFault was specified, this query
returns a +0. If MAXimum was specified, this query returns a +3.
DISPlay:MONitor:PORT:AUTO < state>
Sets the automatic mode for the Display Monitor on or off. When AUTO mode is
ON, the port being monitored is automatically set to the last last port measured.
Parameters
Comments •
a 0 or OFF turns the display monitor automatic mode off; a 1 or ON turns the
display monitor automatic mode on.
•
*RST Condition: sets the automatic mode on.
Example DISP:MON:PORT:AUTO ON Turns automatic display mode on
DISPlay:MONitor:PORT:AUTO?
Returns the state of the automatic display mode as either +0 or +1.
Parameters None.
Comments •
A 0 indicates the automatic display mode is OFF; a 1 indicates the automatic
display mode is ON.
•
*RST Condition: sets the automatic mode on.
Parameter Name Parameter Type Range of Values Default
numeric or discrete 0, 1, OFF, ON OFF
