Heat Controller Water Source Heat Pump User Manual
Page 84
WattMaster WHP
Section 4
4-2
Start-Up and Troubleshooting
Modem
(Optional)
CommLink II
Multiple Loop
Interface
System Manager
#30
#30
#30
#29
#1
#1
#1
#1
RS-485
19200 Baud
RS-485
9600 Baud
RS-485
9600 Baud
RS-485
9600 Baud
RS-485
9600 Baud
Supply
Air
Sensor
RS-485
Comm Loop
24 VAC
Dirty Filter Alarm
or Leaving Water Temp
Room Sensor
with Optional
Override & Adj.
F
Typical WHP Controller Wiring
NOTE: * Only One Outside Air Sensor
is Required per WHP System
110/24 VAC
110/24 VAC
Loop # 1
MiniLink
Loop # 2
MiniLink
Loop # 3
MiniLink
Loop # 4
MiniLink
WHP Loop
Controller
Loop # 4
Network Loop
Power Pak
Power Pak
Local Loop
Local Loop
Typical Network & Local Loop Wiring
2 Conductor Twisted Pair with Shield
(Beldon #82760 or Equivalent)
Local Loop
Local Loop
*OutsideAir
Sensor
Loop #1
Loop #2
Loop #3
See Note #3
Loop #4
24VAC
24VAC
24VAC
24VAC
24VAC
WHP
Controllers
WHP
Controllers
WHP
Controllers
WHP
Controllers
Notes:
1.) 24 VAC Must Be Connected
So That All Ground Wires
Remain Common.
2.) All Wiring To Be In Accordance
With Local And National Electrical
Codes and Specifications.
RELAY
OUTPUT
COM
1-3
OUT
